5G Outdoor Industrial Router FNR410

5G Outdoor Industrial Route Industrial Router 5G Industrial Router

Support 5G LAN
Support FRP NAT Traversal
Support PoE+ Power Input
Support Port Detection & Latency Reporting
Support 4G/5G & WAN Dual-link Failover
Support VPN/PPTP/L2TP/GRE/IPSec/OpenVPN

Trial Sample

Features
Specifications
Download

Cellular Specification

Standard and Frequency	5G	5G REDCAP
	5G NR: n1/n2/n3/n5/n7/n8/n20/n28/n41/n66/n71/n77/n78/n79 LTE: B1/B2/B3/B4(66)/B5(18/19/26)/B7/B8/B12(17)/B13/B14/B20/B25/B26/B28/B29/B30/B38/B39/B40/B41/B42/B43/ B46/ B48/B71	5G NR: n1/n3/n5/n8/n28/n41/n78/n79 LTE-FDD: B1/B3/B5/B8 LTE-TDD: B34/B38/B39/B40/B41
	Note: Band support may vary based on the selected module region.
Theoretical Bandwidth	5G NR: DL 3.4 Gbps; UL 350 Mbps LTE CAT20: DL 2.0 Gbps; UL 150 Mbps HSPA+: DL 42 Mbps; UL 5.76 Mbps	5G NR: DL 226 Mbps; UL 120 Mbps LTE: DL 200 Mbps; UL 100 Mbps

Hardware System

CPU	CPU@880MHz, Dual Core
Flash	128MB
DDR3	512MB

Power Supply

Power Standard	DC 12V/1.5A
Range	DC 9~36V
Operate Current	< 1.1A (12V)

WIFI

Wi-Fi Protocol	IEEE802.11 a/b/g/n/ac/ax (WIFI 6)
Frequency Band	2.4GHz+5GHz
Theoretical Max Bandwidth	2.4GHz 2x2MIMO 11ax (WIFI 6), 0.573 Gbps 5.8GHz 2x2MIMO 11ax (WIFI 6), 1.2 Gbps
Frequency Band	20MHz, 40MHz, 80MHz
Mesh Networking	Supports Mesh Networking with Four-Faith CPE/IDU devices
Wi-Fi Protocol	IEEE802.11 a/b/g/n/ac/ax (WIFI 6)

Interfaces

WAN	Port 1: 1 x 1G Ethernet interface (RJ45), supports auto MDI/MDIX, default LAN (configurable as WAN), and POE+ power reception. Ports 2/3: 2 x 1G Ethernet interfaces (RJ45), support auto MDI/MDIX, for LAN use only.
Aviation Connector	SF13/P7 Aviation Female Connector: Includes serial port and power connections, compatible with SP13/P7 male connector for 1-to-3 power/serial cable. Serial Port: Terminal interface with 1 RS232 (optional RS485) and 1 RS485, equipped with 15KV ESD protection. Power: DC power connector with built-in reverse polarity protection
Indicators	PWR, SYS, Online, WiFi 2.4G, WiFi 5.8G, 5G (tri-color LED)
SIM Card	2 x standard pluggable SIM card slots (compatible with eSIM)
WIFI Antenna	2 standard SMA male antenna connectors with 50Ω impedance.
Cellular Antenna	5G: 4 standard SMA female antenna connectors with 50Ω impedance 5G REDCAP: 2 standard SMA female antenna connectors with 50Ω impedance
Reset	Restoring the parameter configuration to the factory default value

Physical Characteristic

Casing	Metal casing IP66
Dimension	198x159x43mm (Excludes antennas and accessories)
Weight	1195g
Operate Temperature	-35~+75ºC
Storage Temperature	-40~+85ºC
Humidity	100% (No condensation)

Specification

FNR410 5G Industrial Router Technical Specification V1.0.0

User Manual

FNR410 5G Industrial Router User Manual V1.0.0
