Edge Computing Gateway F-G100

Outer shell: metal, IP30 waterproof and dust-proof protection
Standard ports: RS232, RS485, Ethernet, Wi-Fi
CPU: industrial 32-bit processor & wireless module
System: watchdog design, complete mechanisms, stable operation
Other specifications: the F-G100 gateway supports remote management, SYSLOG, SNMP, TELNET, HTTPS, etc.
OS Linux
VPN GRE

Trial Sample

Features
Specifications
Download

Four-Faith Industrial Intelligent Gateway F-G100

● The F-G100 is a wireless intelligent gateway launched by Four-Faith for industrial IoT, and it can provide safe, reliable, and continuous access to the Internet for users through 4G, 5G wireless networks and broadband services.

● The F-G100 gateway adopts industrial-grade designs, including an industrial 32-bit processor and wireless module, and with standard IoT ports including RS232, RS485, and Ethernet LAN, the F-G100 has the capacity to connect multiple devices simultaneously for data transmission.

● The F-G100 has been widely used in M2M fields of the IoT industry, including smart factories, smart cities, smart grids, etc.

Wireless Specification

Project	Content
Module	Industrial wireless module
Standard	5G NR: n1/n2/n3/n5/n7/n8/n20/n28/n41/n66/n71/n77/n78/n79 LTE:B1/B2/B3/B4(66)/B5(18/19/26)/B7/B8/B12(17)/B13/B14/B20/B25/B26/B28/ B29/B30/B38/B39/B40/B41/B42/B43/ B46/ B48/B71
Theoretical bandwidth	5G NR：DL 3.4Gbps，UL 350Mbps LTE Cat20：DL 2.0Gbps，UL 150Mbps HSPA+：DL 42Mpbs，UL 5.76Mbps
Transmit power	<23dBm
Receiving sensitivity	<-97dBm

WIFI Specification

Project	Content
Standard and Frequency	Support IEEE802.11b/g/n，2.4G, 22 MIMO，AP mode，Station mode（optional） Support IEEE802.11ac，5.8G, 22 MIMO，AP mode，Station mode（optional）
Theoretical bandwidth	IEEE802.11b/g：Max Speed 108Mbps IEEE802.11n：Max Speed 300Mbps IEEE802.11ac：Max Speed 780Mbps
Security	Support WEP、WPA、WPA2，WPS Optional
Transmit power	26dBm（11b），21.5dBm（11g），20dBm（11n），16dBm（11ac）
Receiving sensitivity	<-72dBm@54Mpbs

Hardware System

Project	Content
CPU	Industrial 32-bit communication processor
FLASH	32MB
DDR3	512MB
TF	8GB/32GB，optional

Interface

Project	Content
WAN Interface	1 * 10/100/1000M Ethernet（RJ45），Adaptive MDI/MDIX，Built-in 1.5KV ESD Protection
LAN Interface	4 * 10/100/1000M Ethernet（RJ45），Adaptive MDI/MDIX，Built-in 1.5KV ESD Protection
Serial	1 * RS232，5 * RS485（One shared with RS232 interface），Built-in 1.5KV ESD Protection，The serial port parameters are as follows: Data bits: 5, 6, 7, 8 Stop bits: 1, 1.5 (optional), 2 bits Check: no check, even check, odd check, SPACE (optional) and MARK check (optional) Serial port speed: 2400 ~ 115200bits / s
Indicators	"PWR", "SYS", "WIFI", "SIM", "Online","Signal Strength"
I/O Interface	6-pin 3.5mm terminal block; 2 DI, 1 DO, 1 relay Input high level: 5 to 30 VDC Input low level: 0 to 3 VDC Load current <50mA @ 30VDC Relay load: 1A 250VAC / 30VDC
Antenna	Cellular: 2 standard SMA female antenna interfaces, characteristic impedance 50 ohms WIFI: 2 standard SMA male antenna interfaces, characteristic impedance 50 ohms
SIM/UIM	Standard drawer-type user card interface, support 1.8V / 3V SIM / UIM card, built-in 15KV ESD protection
Power	2-pin terminal power socket with built-in reverse power protection
USB	Standard USB3.0 interface, support various USB storage
TF card	Standard bullet TF card interface, support various TF cards
Reset Button	Through this button, the parameter configuration of the smart gateway can be restored to the factory value.

Power Supply

Project	Content
Standard	DC 12V/1.5A
Range	DC 9~36V
Working current	<1.2 A(12 VDC)
Standby current	<800mA(12 VDC)

Physical properties

Project	Content
shell	Metal case, protection class IP30
Size	172x122x38 mm (Excluding antennas and mounts)
Weight	700g

Others

Project	Content
Operating temperature	-35~+75ºC（-31~+167℉）
Storage temperature	-40~+85ºC（-40~+185℉）
Relative humidity	95%(No condensation)

Order Info

Model	Content
F-G100-NR	Cellular (5G NR), WIFI, SIM1, I/O(2DI, 1DO, 1Relay.)
