5G Smart Light Pole Gateway F-G300

smart light pole

● Standard ports: RS232, RS485, Ethernet, Wi-Fi

● CPU: industrial 32-bit processor & wireless module

● System: watchdog design, complete mechanisms, stable operation

● Applied scenarios: smart cities, high-speed highways, municipal government projects, etc.

● Other specifications: the F-G300 gateway supports remote management, SYSLOG, SNMP, TELNET, HTTPS, etc.

Trial Sample

Features
Specifications
Download

Four-Faith 5G Smart Light Pole Gateway F-G300

● Four-Faith’s F-G300 is IoT wireless smart light pole gateway, and it plays the role of transmitting wireless data through public networks in real IoT-applied solutions and other smart interactive scenarios.

● The F-G300 gateway adopts industrial-grade designs, including an industrial 32-bit processor and wireless module. With standard IoT ports including RS232, RS485, and Ethernet ports, the F-G300 gateway has the capacity to connect multiple devices for data transmission.

● The F-G300 gateway has been widely used in M2M fields of the IoT industry, including smart cities, smart transportation, municipal government projects, etc.

Smart light pole gateway Cellular

Project	Content
Cellular Module	Industrial grade module
Frequency	5G NR: n1/n2/n3/n5/n7/n8/n20/n28/n41/n66/n71/n77/n78/n79 LTE:B1/B2/B3/B4(66)/B5(18/19/26)/B7/B8/B12(17)/B13/B14/B20/ B25/B26/B28/B29/B30/B38/B39/B40/B41/B42/B43/ B46/ B48/B71 Remarks: Different modules can support different network standards
Bandwidth	5G NR：DL3.4Gbps UL350Mbps LTE Cat20：DL2.0Gbps UL150Mbps HSPA+：DL42Mpbs UL5.76Mbps
Power	<23dBm
Sensitive	<-97dBm

WIFI

Project	Content
Standard	IEEE802.11b/g/n，2.4G, 22 MIMO，AP mode，Station mode（optional） IEEE802.11ac，5.8G, 22 MIMO，AP mod，Station mode（optional）
Bandwidth	IEEE802.11b/g：108Mbps IEEE802.11n：300Mbps IEEE802.11ac：780Mbps
Security	WEP、WPA、WPA2 encryption
Power	26dBm（11b），21.5dBm（11g），20dBm（11n），16dBm（11ac）
Sensitive	<-72dBm@54Mpbs

Hardware

Project	Content
CPU	Industrial 32 bit processor
FLASH	32MB
DDR3	512MB
TF	8GB/32GB optional

Interface

Project	Content
AC input	1 x 85~264V/35A
AC output	3 x 85~264V/10A，Provide 220V output power supply to the corresponding equipment; remote control switch, voltage and current detection, a single channel allows a maximum current of 10A
DC output	1 x 12V/2A（1 x 24V/2A），Can realize remote switch and current detection
SFP	2 x SFP interface，10/100/1000M SFP slot，Support single-mode, multi-mode fiber, support ring network management, ring, chain and other network topology
WAN	1 x 10/100/1000M Ethernet（RJ45）,auto MDI/MDIX，Built-in 1.5KV electromagnetic isolation protection
LAN	7 x 10/100/1000M Ethernet（RJ45）auto MDI/MDIX，Built-in 1.5KV electromagnetic isolation protection, Among them, 4 channels of POE, support POE+ single channel power up to 30W
Serial	4 x RS485，Built-in 15KV ESD protection： Data bit：5、6、7、8 Stop bit：1、2 Check ：NONE、EVEN、ODD Band rate：2400~115200bits/s
Indicators	"Power", "System", "Online","Signal "
DI	4 x DI Input high level： 5 to 30 VDC Input low level： 0 to 3 VDC
DO	2 switch output DO, load current: <50mA @ 30VDC
Relay	2 passive relay control outputs, relay load: 5A 250VAC/30VDC
AI	2 x 4~20mA ADC interface
GPS	1 x GPS
Antenna	Cellular:4x Standard SMA female antenna interface, characteristic impedance 50 ohm WIFI：2x Standard SMA female antenna interface, characteristic impedance 50 ohm GPS：1x Standard SMA female antenna interface, characteristic impedance 50 ohm(optional)
SIM/UIM	2 standard drawer type user card interfaces, support 1.8V/3V SIM/UIM card, built-in 15KV ESD protection (Remarks: Compatible with e-SIM)
TF	1 x TF card interface
Reset	Through this button, the parameter configuration can be restored to the factory value

Power Supply

Project	Content
Shell	Metal case , IP30 protection
Size	215134.770.2mmmm (Does not include antenna and mounting parts)
Weight	1.8kg(Does not include antenna and mounting parts)

Physical

Project	Content
Operating Temperature	-35~+75ºC（-31~+167℉）
Storage Temperature	-40~+85ºC（-40~+185℉）
Humility	95%(No condensation)

Others

Project	Content
AC	AC 85~264/35A(max)
Operating	0.15~0.25A(All output ports are empty)
Standby	0.1A(All output ports are empty)

Order Info

Mode	Content
F-G300	Cellular (5G-NR), WIFI, SIM*2

Specification

F-G300 5G Smart Light Pole Gateway Technical Specification V2.0.0
