Speed Dome Camera

● Abundant ports: RS232, RS485, and customized IoT ports

● Large angle adjustment: horizontal 0-360 degrees, vertical 0-90 degrees

● Industrial-grade design: IP66 protection level, stability, and durability

● Other specifications: up to 140dB wide dynamic range to ensure all the bright and dark areas are well presented

Trial Sample

Features
Specifications
Download

Four-Faith F-SC431 HD Camera

● F-SC431 is a large HD camera that can precisely adjust the angle horizontally 360 degrees and vertically 90 degrees, without the blind monitoring areas.

● With standard ports like RS232 and I/O, F-SC431 can connect different devices, and it also supports customized IoT ports to meet the different demands of various IoT-applied scenarios.

● The F-SC431 has been widely used in smart fields like smart cities, smart transportation, and commercial buildings, etc.

F-SC431 HD Speed Dome Camera

SPECIFICATION
Model	F-SC431-25
CAMERA
Image Sensor	1/2.8″ Progressive Scan CMOS
	2MP
Min. Illumination	Color: 0.002Lux@F1.2 B/W: 0Lux with IR on

F-SC431-25
2 Megapixel H.265 Speed D Network Came	1/1&G.711/AAC
KEY FEATURES  H.265, optimized in bit rate, bandwidth and storage usage, 50 off than H.264.  Super WDR, up to 140dB wide dynamic range ensure all the bright and dark areas are well presented.  IP66, industrial level protection, provides solid stability and durability.  30X AF Lens, keep the clarity and deliver the high-quality image.	1
Alarm Out*	1 (Port can Drive 12V or 5V Relay)
Relay Out*	1
Power Return Out*	12V@500MA or 5V@1000MA
ADC In*	1@8bit
UART Port*	TTL@115200bps or Expansion for RS485
USB Port*	Expansion For 4G Or WiFi
Type	Junction Box Version for Multiple External Interfaces Or Cable Out Version for Single External Interface
GENERAL
Working Temperature -40℃~60℃
Working Humidity	0~90% (Non-condensing)
Power Supply	PoE (802.3at)
Power Consumption	10W MAX 30W MAX (With IR on)
Weather Proof	Up to IP66-rated for Weather-resistant Performance
Weight	5.2kg (Junction Box Version) 4.2kg (Cable Out Version)
Dimensions	Φ204.8mmX308mm
Warranty	2 Year
DIMENSION (mm)		200

F-SC431-25

2 Megapixel
H.265 Speed D Network Came

KEY FEATURES
    H.265, optimized in bit rate, bandwidth and storage usage, 50 off than H.264.
    Super WDR, up to 140dB wide dynamic range ensure all the bright and dark areas are well presented.
    IP66, industrial level protection, provides solid stability and durability.
    30X AF Lens, keep the clarity and                                                   deliver the high-quality image.

Model

Megapixel

Lens

Optional Functions

F-SC431-25-
M51143331301

2MP

30X
AF Motorized Lens

SD, DC&POE

Naming Convention

F‐SC431‐25‐ M51143331301
Speed Dome

1-Fixed Lens
4-Motorized Lens
5-AF Motorized Lens

No.

Function

Power
Interface

LAN Port

SD Card

IR LED

UART
Interface

ADC

DI&DO

RELAY

Audio

USB

Cable Outlet

1‐POE

1‐100Mb/s Ethernet Port

1‐SD card slot

4‐3 Sets of Adjustable IR LED

1‐TTL

1‐Photosensitive ADC
2‐Photosensitive ADC
+ ADC for AF Lens Temp
3‐ Photosensitive ADC
+ External Interface

1‐DI

1‐RELAY1

1‐Audio In 2‐Audio Out 3‐Audio In&Out

1 ‐ Cable

5‐POE & DC

2‐RS232

2‐DO

2‐RELAY2

2 ‐ Junction Box

Code
(0‐None)

3‐RS485
4‐GPS

3‐DI&DO

3‐RELAY
1&2

5‐LORA
